The revolutionary Meybo HSX frame is set to become one of the fastest frames at the race track. After 5 years in development; the World Cup winning Holeshot geometry is now available with all new factory features allowing for optimal power transmission and the ideal combination of stiffness and handling.
-
- Meybo HSX frame features include:
- Meybo fixed length chainstay with 15mm rear drop outs
- > Ensure you always have the same Chainstay length whatever gear you run
- > Easy; fast and straight mounting of your rear wheel
- > Disc brake directly mounted on the frame; no adaptor needed
- 6061 T-6 multiple butted hydroformed tubing
- Unique CNC Alloy / PE1000 Meybo chain tensioner system
- Supplied with 7005 CNC 15mm rear axle
- Disk brake only; no V-Brake mounts
- Uses flat mount disk brake and 120mm disk rotor
-
- Expert frame geometry:
-
- Head Tube angle: 73.5º
- Top Tube length: 500mm / 19.7''
- Chainstay length: 340mm / 13.4''
- Head Tube size: 1 1/8''
- Seat Post size: 25.4mm
- 15mm rear drop out
- BB86
- Weight TBA
SKU K2954
Brand Meybo
